Outlander 400"Never in our testing has one ATV so dominated a category. The Bombardier Outlander 400 4x4 was the clear winner of this comparison. This is our pick for best recreational-utility machine in its class." ATV Magazine

"The introduction of the Outlander MAX will no doubt cause the biggest splash, because it is a real recreational two seater ATV. It combines comfort and performance in a good looking package. Nothing will ever be the same in the industry, because more and more two passenger quads will be taking the trails." ATV Rider

Standard Features:details

  • TTI independent rear suspension
  • Visco-Lok auto-locking differential
  • SST frame
  • Inboard disc brakes.





Action Shot

Outlander 400 H.O. Specifications
Features

Instrumentation:

 Speedometer, odometer, trip and hourmeter, fuel gauge
Electrical: Pre wired for winch
Lighting: 2 fender-mounted headlamps (30 W) w/ tail light/brake light
DC Outlet: Lighter type in console, standard connector in the back (15A)
XT Package Content
Available:		 Warn‡ 2500 CI winch, agressive tread Carlisle‡ ACT radial tires, heavy duty front & rear bumpers, handguards
Available Colors: Yellow, red, green, camo
Engine
Type: 400cc, 4-stroke, single, liquid-cooled, 4-valve SOHC
Bore & Stroke 91 x 61.5 mm
Torque /
Net Power:		 32 Nm @ 5,500 RPM
Carburetion/EFI: Carburetion, Mikuni BSR 33
Starting System: Electric w/ auxiliary coil
Transmission: CVT, sub-transmission with high, low, park, neutral & reverse
Drive Train: Selectable 2x4/4x4 shaft driven with Visco-Lok front differential
Chassis
Frame: SST

Front Suspension
Type:

MacPherson
Front Suspension
Travel:		 7 in (178 mm)
Rear Suspension
Type:		 TTI independent
Rear Suspension
Travel:		 8.0 in. (203.2 mm)
Front Brake: 2 inboard hydraulic discs
Rear Break: 1 inboard hydraulic disc
Front Tires: 25 X 8 X 12 in. (660 x 203 x 305 mm)
Back Tires: 25 X 10 X 12 in. (660 x 254 x 305 mm)
Dimensions
L x W x H in: 86 x 46 x 45
L x W x H meter:
2.184 x 1.168 x 1.143
Wheelbase: 49 in. (1,244 mm)
Dry Weight: 592 lb. (269 kg)
Ground
Clearance: 		9.3 in. (236 mm)
Seat Height: 35 in. (877 mm)
Rack Capacity:
(Front & Rear) 		90 lb. (40 kg), 175 lb. (80 kg)
Towing Capacity: 1,100 lb. (500 kg)
Fuel Capacity: 4.2 US gal. (16 L)


Head Back to 2005 Models
